QS Motor 10000W 273 70H V3 E-Car Hub Motor

Motor Design: Singleh axle without rim

Matched Wheel: ≥14inch Car Wheel, PCD customizable, CB ≥60mm (PCD 5*112mm, CB60mm as default)

Magnet Height: 60mm, 16 pole pairs

Stator: Aluminmum Core

Rated Power: 10000W (20kW peak in few seconds)

Rated Voltage: 96V as default (48V-144V, optional)

Speed: 120KPH as default (70-130KPH, optional)

kV: 10.0/10.28(as default)/10.42/11.67/12.5/14.58/ etc

Max Torque: more than 350N.m

Max Efficiency: 86-91%

Peak Battery Current: 200A (96V)

Suggest Peak Phase Current: 500-600A

Thermic Probe: KTY83/122 (as default, optional)

Brake type: Disc brake, PCD4x114.3mm-M12, CB 67mm(as default)

Dual Hall Set with waterproof connectors

2x12m㎡; Cross Section of Phase Wire (not include insulation layer)

Hall Sensor Phasing angle: 120 degree

Waterproof Grade: IP54

Color: Black

N.W./G.W.: 32kg/35kg

Package Dimension: 48cm*50cm*54cm/piece(wodden package)
