QS273 Spoke Hub Motor(40H) 4000W V3 Type

QS273 Spoke Hub Motor(40H) 4000W V3 Type

Motor Specification:

1. Motor Type: BLDC Hub Motor with Permanent Magnets

2. Motor design: Double axle out with spoke hub motor

3. Number of Spoke hole:36 pcs

4. Magnet Height: 40MM

5. Pole Pairs: 16 pairs

6. Rated Power: 4000W

7. Max Power:8000W

8. Rated Voltage: 72V( 48-96V Can be optional)

9. Max No-load RPM:500-1200RPM can be customized

10. Max Torque: 200N.M

11. Max Efficiency: 88%

12. Continious current:67A

13. Max current:80A Peak 140A

14. Brake type: Disc brake

15. Rear Fock width for installation: 200mm

16. Cross Section of Phase wire: 16 mm2

17. Hall sensor phasing angle: 120 degree

18. Temperature Sensor: KTY83-122

19. Max. Working Temperature: 70-120 degree, Peak 150 degree

20. Waterproof Grade: IP66

21. N.W./ G..W. : 21kgs / 22kgs

22. Package Size: 44*43*34CM
