QS273 Spoke Hub Motor(45H) 6000W V3 Type

QS273 Spoke Hub Motor(45H) 6000W V3 Type

273 Spoke Hub Motor Designed for electric motorcycle, the rated power can be made,5kw,6kw,7kw or 8kw. Max speed can be customized from 80-120KMPH.

Motor Specification:

1. Motor Type: BLDC Hub Motor with Permanent Magnets

2. Motor design: Spoke Motor with Double axle out

3. Spoke Hole: 36pcs*4.2mm

4. Matching Wheel: 17inch-19inch spoke wheel

5. Magnet Height: 45MM

6. No. of Pole Pairs: 16 pairs

7. Rated Power: 6000W

8. Max Power:7905W(Peak 12000W)

9. Rated Voltage: 72V( 72-144V Can be optional)

10. Speed: 110km/h (30-110km/h can be customized)

11. Max No-load RPM:1339RPM

12. Max Torque: 200N.M

13. Max Efficiency: 90%

14. Continious current:91A

15. Max current:119A ,Peak 180A

16. Brake type: Disc brake

17. Rear Fork width for installation: 200mm

18. Winding Core material: Aluminium

19. Cross Section of Phase wire: 16 mm2

20. Hall sensor phasing angle: 120 degree

21. Temperature Sensor: KTY83-122

22. Max. Working Temperature: 70-120 degree, Peak 150 degree

23. Waterproof Grade: IP66

24. N.W./ G..W. : 22kgs / 23kgs

25. Package Size: 44*43*34CM
