QS260 12in E-Scooter Hub Motor( 1000W V1 Type

QS260 12inch E-Scooter Hub Motor(27H) 1000W V1 Type

Motor Specification:

1. Motor Type: BLDC Hub Motor with Permanent Magnet

2. Motor design: Double axle out with 12inch rim

3. Rim size:3.5x12,2.5x12

4. Matching Tire: 120/70-12, 130/70-12

5. Magnet Height: 27MM

6. Pole Pairs: 24 pairs

7. Rated Power: 1000W

8. Max Power: 1600W

9. Rated Voltage: 48V,60V,72V

10. Max. Speed: 50KPH

11. Max No-load RPM: 650RPM(Can be customized)

12. Max Torque: 110N.M

13. Max Efficiency: 88%

14. Continious current:25A

15. Max current:45A

16. Brake type: Disc brake or drum brake

17. Rear Fork width for installation: 200mm

18. Cross Section of Phase wire: 4 mm2

19. Hall sensor phasing angle: 120 degree

20. Temperature Sensor: Optional

21. Max. Working Temperature: 70 degree, Peak 120 degree

22. Waterproof Grade: IP67

23. N.W./ G..W. : 15kgs / 16kgs

24. Package Size: 44*43*34CM
