QS260 12in E-Scooter Hub Motor 8000W V4 Type

12inch 260 E-Scooter Hub Motor(60H) 8000W V4 Type

Motor Specification:

1. Motor Type: BLDC Hub Motor with Permanent Magnets

2. Motor design: Double axle out with 12inch rim

3. Rim size:3.5x12

4. Matching Tire: 120/70-12, 130/70-12

5. Magnet Height: 50MM

6. Pole Pairs: 16 pairs

7. Rated Power: 8000W

8. Peak Power: 15000W

9. Rated Voltage: 72V

10. Speed option:

11. Max Torque:300N.M

12. Max Efficiency: 89%

13. Continious current:120A

14. Max current:200A

15. Brake type: Disc brake

16. Rear Fork width for installation: 230mm

17. Hall sensor: Two group of Hall sensors(Model:SS413F)

18. Winding Frame material: Aluimium

19. Cross Section of Phase wire: 16mm2

20. Hall sensor phasing angle: 120 degree

21. Temperature Sensor: KTY83-122

22. Max. Working Temperature: 70-120 degree, Peak 150 degree

23. Waterproof Grade: IP66

24. Working system: S9

25. Cooling method: Natual

26. Color: Black

27. N.W./ G..W. : 20kgs / 22kgs

28. Package Size: 44*43*34CM
